Description
Details
Features:
CCID-compliant PC/SC-compliant Read/write speed up to 424 kbps Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type) Supports ISO 14443 Type A and B, Mifare, FeliCa, and all 4 types of NFC (ISO/IEC 18092) tags Built-in anti-collision feature (only 1 tag is accessed at any time) User-controllable bi-color LED User-controllable buzzer
Applications:
e-Government e-Banking and e-Payment e-Healthcare Transportation Network Security Access Control Loyalty Program
Technical Specifications :
Dimensions
98mm(L) x 65mm(W) x 12.8mm(H)
Weight
70g
Interface
USB Full Speed
Operating Distance
Up to 50mm (depends on the tag type)
Supply Voltage
Regulated 5V DC
Supply Current
200mA(operating); 50mA (standby); 100mA (normal)
Operating Temperature
0-50°C
Operating Frequency
13.56 MHz
Smart Card Interface Support
ISO14443 Type A & B
Mifare
FeliCa
4 types of NFC (ISO/IEC18092) tags
Compliance/Certifications
PC/SC,CCID,CE,FCC,VCCI,RoHS Compliant,USB Full Speed
Microsoft ? WHQL: 2000, Server 2003, XP,Vista, Server 2008, Server 2008 R2, 7
Operating System Support
Win98, WinME, Win2000, Win XP, Win Vista, Win7, Win Server 2003, Win Server 2008
Win XP x64, Win Vista x64, Win 7 x64, Win Server 2003 x64, Win Server 2008 x64, Win Server 2008 R2 x64
